Introducing the S2-6V Solar Charge Controller: Powering Your Devices, Protecting Your Investment

Experience the ultimate in solar charging technology with the S2-6V, a robust and energy-efficient charge controller designed for 6-volt systems. Perfect for anyone seeking reliable power management for their solar applications, this versatile unit offers advanced features that enhance performance, prolong battery life, and simplify solar system maintenance.

Why Choose the S2-6V?

• Built to Last: Comes with a 5-year warranty, giving you confidence in long-term performance and durability.
• Automatic Night-Time Shutdown: Save energy and protect your system with intelligent automatic shutdown when the sun sets.
• 3-Stage PWM Charging: Ensure optimal charging with Pulse Width Modulation (PWM), which adjusts the charging rate in bulk, absorption, and float modes to extend your battery’s lifespan.
• Temperature Compensation: Built-in temperature control ensures your system stays efficient across extreme temperatures.
• Eco-Friendly Design: Manufactured with solar power and fully encapsulated in epoxy potting for rugged protection from environmental elements.
• Proudly North American Made: Engineered and crafted in North America with high standards of quality and sustainability.

Key Specifications

• Operating Temperature: -40°C to 50°C / -40°F to 120°F
  Withstands even the most extreme weather conditions.
• Compact and Lightweight: Weighs just 90 grams (3.2 oz.) and measures 5.1 x 5.1 x 3.8 cm (2 x 2 x 1.5 in.), making it easy to integrate into any setup.
• Sealed ABS Case: Fully sealed in epoxy for exceptional durability and protection.
• Wire Leads: 18 AWG, 15 cm (6 in.) for easy and secure connections.
• Smart LED Indicators:
  • 3 Flashes: Charging in progress
  • 2 Flashes: Bulk Voltage reached
  • 1 Flash: Float Mode for maintenance charging

Powerful Performance with Smart Efficiency

• Voltage Configuration: 6 Volts
• Minimal Power Consumption: Only 0.2 mA at night and 0.6 mA in daytime standby, ensuring your system stays energy-efficient.
• Maximum Input Voltage: 25 Volts
• Charging Current: Delivers up to 2.5 Amps DC for reliable and fast charging.
• Smart Charging Setpoints:
  • Bulk charge: 7.2 Volts
  • Float charge: 6.8 Volts
  • (Custom setpoints available)

Tailored to Your Needs

Customize the S2-6V to match your unique requirements, contact us for additional information:

• Turn off temperature compensation for specific environments.
• Custom voltage setpoints to match your power needs.
• Custom wire lead lengths for a perfect fit.
• Lithium Battery Protection: Optional protection ensures safe operation in cold temperatures (no charging below 4°C).
