This MS-PAE series inverter by Magnum Energy is rated for 4400W/48V. The MS-PAE Series Inverter/Charger from Magnum Energy is a pure sinewave inverter designed specifically for the most demanding renewable energy applications. The unique design of the MS-AE Series provides two 120VAC output lines that are 180 degrees out-of-phase with each other, so that the combination of the L1 and L2 lines total 240VAC and the voltage between either L1 or L2 and neutral is 120VAC, eliminating the need to purchase two units and stack them together to get 240 volts.

When the power requirements of the system are beyond the capacity of a single MS-PAE Series inverter or the system is expanded as more loads are added, up to four MS-PAE Series inverters can be connected together in a parallel configuration. When connecting MS 4448PAE inverters in parallel, the overall Magnum pure sine wave inverter power and surge capacity is increased to power a large single load or more smaller loads.

The MS-PAE Series inverters are powerful, easy-to-use and ETL listed to the stringent requirements of UL 1741 and CSA C22.2 No. 107.1-01 for Renewable Energy installations. For more information on this Magnum sine inverter, see the Documents tab.
